GE Economical Plastic Recycling Crusher with Uniform Flakes
GE series is used economically for handling the defects during injection molding, sprue, pipes, profiles, sheets, films and nozzles. Ilt is everlasting and easy to clean with longer service life.
A series of auxiliaries such as blowers,exhausters,conveyors,metal detectors are available upon requests.
Different applications require different rotor types but one aspect is the same on all ACERETECH rotors -the well proven chevron“V"-cut technology It not only reserves the advantages of cross cut technology, but also guarantee the cutting point only at the place where the blades cross instead of the whole blade. lt considerably ensures lower noise,less powder and prolongs the service life, thus saving the energy."V"-cut technology drives the materials towards the centre of the rotor and solves the problems such as stacking materials inside, heat from rubbing and excessive side-wall friction.
Application
GE series crusher is particularly suitable for online crushing and recycling of plastic products production lines. It has special cutting technology to recover various small hollow materials, including injection mold parts, blow mold parts, profiles, sheets, films and other materials. The recycled flakes are uniform.
Final Products
GE Economical Plastic Recycling Crusher with Uniform Flakes
GE series is used economically for handling the defects during injection molding, sprue, pipes, profiles, sheets, films and nozzles. Ilt is everlasting and easy to clean with longer service life.
A series of auxiliaries such as blowers,exhausters,conveyors,metal detectors are available upon requests.
Different applications require different rotor types but one aspect is the same on all ACERETECH rotors -the well proven chevron“V"-cut technology It not only reserves the advantages of cross cut technology, but also guarantee the cutting point only at the place where the blades cross instead of the whole blade. lt considerably ensures lower noise,less powder and prolongs the service life, thus saving the energy."V"-cut technology drives the materials towards the centre of the rotor and solves the problems such as stacking materials inside, heat from rubbing and excessive side-wall friction.
Application
GE series crusher is particularly suitable for online crushing and recycling of plastic products production lines. It has special cutting technology to recover various small hollow materials, including injection mold parts, blow mold parts, profiles, sheets, films and other materials. The recycled flakes are uniform.
Final Products
Technical specification | GE500/500 | GE500/700 | GE500/1000 | GE500/1400 |
Machine Weight(KG) | 2500 | 3500 | 4200 | 6000 |
Machine dimension(mm) | 1125x1910x2310 | 1330x1920x2510 | 1650x1910x2640 | 2050x1910x2710 |
Chamber size(mm) | 540*540 | 540*700 | 540*990 | 540*1400 |
Power(kw) | 30 | 37 | 55 | 75 |
Rotoary blades quantity | 5 | 5 | 5 | 5 |
Stator blades quantity | 2 | 2 | 2 | 2 |
Rotor diameter | 500 | 500 | 500 | 500 |
Rotor width | 500 | 700 | 1000 | 1400 |
Technical specification | GE500/500 | GE500/700 | GE500/1000 | GE500/1400 |
Machine Weight(KG) | 2500 | 3500 | 4200 | 6000 |
Machine dimension(mm) | 1125x1910x2310 | 1330x1920x2510 | 1650x1910x2640 | 2050x1910x2710 |
Chamber size(mm) | 540*540 | 540*700 | 540*990 | 540*1400 |
Power(kw) | 30 | 37 | 55 | 75 |
Rotoary blades quantity | 5 | 5 | 5 | 5 |
Stator blades quantity | 2 | 2 | 2 | 2 |
Rotor diameter | 500 | 500 | 500 | 500 |
Rotor width | 500 | 700 | 1000 | 1400 |
FEEDING
>>> Motor drives of conveyor belt and hauling device cooperate with abb inverter. feeding speed of conveyor belt or roll hauling of is fully automatic.
UNIFORM GRINDING
>>> We have more than twenty different knife designs such as double-shear V-shaped cutting. They can achieve uniform particle size and less dust after crushing. Modular cutting chamber. Select suitable knives and screen according to material characteristics.
>>> Alloy steel rotary and fixed knives are made by European supplier.
EASY MAINTENANCE
>>> Optimized crushing chamber, with help of the hydraulic controlling open and close, it’s easy to clean the inner chamber and rapidly replace parts.
STABLE POWERTRAIN
>>> The drive motor and gear box are of European brands, with high efficiency of energy utilization for long-term stable running.
FEEDING
>>> Motor drives of conveyor belt and hauling device cooperate with abb inverter. feeding speed of conveyor belt or roll hauling of is fully automatic.
UNIFORM GRINDING
>>> We have more than twenty different knife designs such as double-shear V-shaped cutting. They can achieve uniform particle size and less dust after crushing. Modular cutting chamber. Select suitable knives and screen according to material characteristics.
>>> Alloy steel rotary and fixed knives are made by European supplier.
EASY MAINTENANCE
>>> Optimized crushing chamber, with help of the hydraulic controlling open and close, it’s easy to clean the inner chamber and rapidly replace parts.
STABLE POWERTRAIN
>>> The drive motor and gear box are of European brands, with high efficiency of energy utilization for long-term stable running.
